| Input Voltage | 12V DC |
| Stroke (Movement) | 24" |
| Force | 175lbs (750N) |
| Speed (mm/sec) |
12mm/sec |
| IP Rating (Protection Class) - IP54 |
*Ingress of dust is not entirely prevented, but it must not enter in sufficient quantity to interfere with the satisfactory operation of the equipment *Water splashing against the enclosure from any direction shall have no harmful effect |
| Operational Temperature | -4F ~ +149F |
| Noise | <45db |
| Limit Switch | Built in, Non-Adjustable |
| Current | 6.5 Amps |
| Mounting Hole | 6mm |
| Fully Retracted | 281/4" |
| Full Extended | 521/4" |
| Cycle | 25% |
| Warranty | 12 Months |
